DoorKing 6100-071 Swing Gate Operator Parts
For a high-cycle device like this, every part must work together with precision. If you need to replace a part of your DoorKing 6100 pad-mount operator, you can find it here in our EPV. North Shore Commercial Door provides EPVs (Exploded Parts Views) to help create and maintain our standing as a hub for the informed consumer of all entryway needs. These drafting-style images will help you find, identify and easily order the big or small replacement parts you need.
Can’t find the items you’re looking for? Do you have questions about products? Give our sales and service team a call on weekdays from 8 am to 4:30 pm (Eastern) at 800.783.6112. Get a fast reply by chat: click “chat live” link near the bottom of our homepage. As always, you can email us anytime at support@northshorecommercialdoor.com
| Key | Part # | Description |
|---|---|---|
| 1 | 6100-871 | DoorKing 6100-871 - IPB-Pad Mount 6050/6100 Swing Gate Operator DISCONTINUED |
| 3 | 2600-781 | DoorKing 2600-781 Left Leg Plated 6050/6100 |
| 5 | 2600-780 | DoorKing 2600-780 Right Leg Plated 6050/6100 |
| 7 | 2600-782 | DoorKing 2600-782 Base Plated 6050/6100 |
| 9 | 2600-716 | DoorKing 2600-716 Crank Arm Model 610 605 Blk |
| 11 | 2600-714 | DoorKing 2600-714 Connecting Rod 1" x 2" x 60" |
| 13 | 2600-179 | DoorKing 2600-179 Release Handle 6050,6100,6300 |
| 15 | 2600-767 | DoorKing 2600-767 Lock Padlock Brass B745C |
| 17 | 2600-054 | DoorKing 2600-054 Spacer 3/4 OD x 1/2 ID x 1 1/8 L |
| 21 | 2615-052 | DoorKing 2615-052 Bolt Hex Head 3/8-16 x 1 |
| 25 | 2615-084 | DoorKing 2615-084 Bolt Hex Head 1/2-13 x 2 1/2 |
| 31 | 2620-047 | DoorKing 2620-047 Lockwasher 3/8 |
| 33 | 2620-021 | DoorKing 2620-021 Washer 1/2 SAE |
| 41 | 2620-405 | DoorKing 2620-405 Nut Hex 3/8-16 |
| 43 | 2620-411 | DoorKing 2620-411 Nut Hex Flange Lock 5/16-18 |
| 45 | 2620-320 | DoorKing 2620-320 Nut Center Lock 1/2-13 |
