Hormann SD7500 Garage Door Opener Circuit Board

SKU:: D437634

Usually Ships 4 to 7 Business Days

UPC:
availability:: available

Current Stock:

MSRP: $138.66

$126.05

(You save $12.61 )

Quantity:

Adding to cart… The item has been added

Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

Product Description
Related Products

Product Description

Hormann SD7500 Garage Door Opener Circuit Board Part # D437634 Note: In cases where a confirmed lightning strike, check to ensure the opener will open the door. If the motor has no red light and the door will not move, you will need a new motor assembly.

HOW TO REPLACE THE CIRCUIT BOARD:

Make sure the opener is unplugged from the outlet.
Remove the light bulbs.
Remove the plastic cover covering the head assembly.
The board is at the back of the head and is secured in place by 4 plastic tabs. With slight pressure, push on the two tabs at the edge of the board closest to the actual motor itself.
The board should pop free, and then you can slide it from under the other two tabs.
There are 5 wiring assemblies that must be unplugged, and then the board is completely free of the head.
Reverse the process to install the new board.
